Optical Metrology

The Optical Thickness Gauge products from Bristol Instruments will benefit any engineer who needs to know the exact thickness of their material for development and production applications in industries such as these.

opticalcomponents

OPTICAL COMPONENTS AND LENS ASSEMBLIES
Measures individual components and multi-element stacks, including air gaps

contactlenses
vehicledisplay

CONTACT AND INTRAOCULAR LENSES
Measures center thickness, sagittal height and group index

AUTOMOTIVE
Measures up to 31 layers of high-resolution vehicle displays and autonomous driving camera systems

medicaltubing

MEDICAL TUBING AND CATHETERS
Simultaneously measures wall thickness, inner and outer diameter of tubing, as well as wall thickness of body, neck and cone of catheters

LCD, LED, OLED AND AMOLED DISPLAYS
Measures total and individual layer thickness including LOCA (liquid optically clear adhesive) layers

VIRTUAL REALITY GOGGLES/AUGMENTED REALITY
Measures total and individual layer thickness including LOCA (liquid optically clear adhesive) layers

semiconductors

SEMICONDUCTORS
Measure Silicon/GaAs wafers

glasslimming

GLASS SLIMMING
Measures thickness before and after the chemical etching and/or polishing process to make glass sheets thinner and lighter

analysis-background-bacteria-2280547

For the most demanding applications

The evolution of items such as optical components, electronic displays, medical devices, glass tubing, and ophthalmic products has driven the need for more precise manufacturing processes.

Increasingly tight tolerances for critical dimensions, such as material thickness, must be maintained, making it important to have a reliable method of measurement.

Bristol Instruments offers thickness gauges that are specifically designed to address these advanced manufacturing requirements.

Thickness Measurement Products

Bristol Instruments provides a family of optical thickness gauge products for researchers and manufacturing engineers who need to know the exact thickness of their material.

optical-thickness
View Thickness Gauges
